Internorm Windows, Ballymena

Whether you are a homeowner, property developer or architect, we have a range of incredible Internorm windows for you in Ballymena and its surrounding windows. Discover our online quoting engine or contact form, and you can receive a free quote today!

Whether you are a homeowner, property developer or architect, we have a range of incredible Internorm windows for you in Ballymena and its surrounding windows. Discover our online quoting engine or contact form, and you can receive a free quote today!

Internorm Ambiente Ballymena

Passive House Windows in Ballymena

Our Internorm windows are available in various customisable choices. Each window in our range has triple glazing options as standard, although you can opt for double glazing too – whatever you decide, Internorm windows are designed to exceed Passive House Standards.

With Internorm’s innovative design, your new Ballymena Internorm windows are available in Home Soft, Home Pure, Studio and other ambient styles. You can have various options to choose from for your next home improvement project, with each of these creating a separate atmosphere and class for your Ballymena property.

Your new windows will deliver performance enhancing benefits like maximum security, thermal efficiency and weatherproofing abilities. Whatever your priority, Internorm windows can give you the home improvement service that you need to get the very best products on the market.

Get A quote
Internorm window prices Ballymena

Internorm uPVC Windows in Ballymena

As one of the most popular choices amongst homeowners and property developers in the Ballymena area, the Internorm uPVC window design combines both passive house standards with modern uPVC profiles to enhance the appearance and performance of your property truly.

Additionally, every uPVC triple glazed Internorm window can be manufactured and fitted with the latest hardware features to provide your property with a modern home improvement solution. With add-ons like Internorm’s I-tec solution, your building can benefit from enhanced security and thermal insulation properties to last you for many years to come.

Internorm windows come with I-tec Glazing as standard; this means that this particular system has a triple or double glazed pane with the window sash. In other words, no matter the time of year, even in the unpredictable Irish weather, your property will be protected from extreme weather conditions.

Request a Quote

Internorm uPVC Window Profiles

KF 310

uPVC

Homepure KF310 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,69

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Homesoft KF310 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,69

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Studio KF310 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,69

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

KF 320

uPVC

Homepure KF310 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,65

Internorm Sonic Icon

Sound Reduction (in dB)

35 - 45

Internorm Security Icon

Security

up to RC1N, RC2

KF 410

uPVC

Homepure KF410 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,62

Internorm Sonic Icon

Sound Reduction (in dB)

34 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Homesoft KF410 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,62

Internorm Sonic Icon

Sound Reduction (in dB)

34 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Studio KF410 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,62

Internorm Sonic Icon

Sound Reduction (in dB)

34 - 45

Internorm Security Icon

Security

up to RC1N, RC2

KF 520

uPVC

Homepure KF410 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,63

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 46

Internorm Security Icon

Security

up to RC3, RC2

KF 410 - uPVC Profile

The KF 410 has a complete flush transition from sash to frame, completing this window as one unit. Once the frame is rendered into the brickwork on three sides, only the unique narrow and square edged sash frame remains visible.

With low U-values, it’s a cost efficient window option with compliant accreditations. Secured By Design and Lifetime Homes accreditations make them an ideal option for any home. Intelligent Internorm technology is integrated into this KF 410 style window system.

I-tec innovations such as I-tec Glazing and I-tec Ventilation ensure optimum stability, thermal insulation and security. These windows are controlled at the touch of a button, enabling simple and stress free operation of your window via smartphone or tablet.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0.62

Internorm Sonic Icon

Sound Reduction (in dB)

34 - 45

Internorm Security Icon

Security

Up to RC1N, RC2

Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimensions (in mm)

  • Frame construction depth 90
  • View width frame/sash 113
  • View width flying mullion (2 sashes) 133
  • View width transom/mullion (2 sashes) 187

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Light grey

KF 520 – uPVC Profile

KF 520 uPVC windows combine innovative design with advanced technology. This window meets the highest standards of burglary protection, with I-tec Secure and innovative locking systems.

Integrated flaps press on all sides into the frame interior when locking and thus ensure maximum burglary protection.

The sleek frame offers excellent thermal efficiency and sound reduction for maximum comfort. Optional built in ventilation can be added into the window frame with the I-tec Ventilation system. I-tec Glazing gives stability, thermal insulation, and security due to the all round bonding of the glass pane.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,63

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 46

Internorm Security Icon

Security

up to RC3, RC2

Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 90
  • View width frame/sash 85
  • View width flying mullion (2 sashes) 96
  • View width transom/mullion (2 sashes) 148

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Light grey

KF 310 – uPVC Profile

The traditional and sophisticated KF 310 has a sleek appearance alongside reliable technology. This range of windows is characterised by thermal insulation and impressive sound reduction values.

With a round bonded glass pane, the KF 310 is available in a large selection of colours, glazing and handles. They can also make the ideal addition to the balcony and patio doors, with integrated Juliet balcony.

I-tec glazing ensures excellent stability. The glass pane is glued all around the frame, ensuring superior levels of security and thermal insulation.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,69

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 90
  • View width frame/sash 85
  • View width flying mullion (2 sashes) 96
  • View width transom/mullion (2 sashes) 148

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Light grey

KF 320 – uPVC Profile

The innovative glass sash of the KF 320 gives the impression of fixed glazing, yet it is still an openable window. The narrow, square edged window frame highlights the minimal architecture of the window design.

This straight lined window profile has an appealingly consistent design. Externally, the opening sash is covered by the window frame. The narrow offset between the frame and the glass pane enhances the flush mount aesthetics The glass sash gives the impression of a fixed glazed unit, yet it is an operable window.

Three sided rendering of the frame achieves modern and almost frameless glass architecture. I-tec glazing ensures excellent stability, thermal insulation and security through surrounding bonding of the glass pane.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,65

Internorm Sonic Icon

Sound Reduction (in dB)

35 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 71
  • View width frame/sash 97
  • View width flying mullion (2 sashes) 100
  • View width transom/mullion (2 sashes) 154

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Light grey

KF 310 – uPVC-Aluminium profile

The FK 310 is a slim window with a construction depth of 74 mm. The rounded edges of sash and frame match design is elegant and cosy.

The strong aluminium cladding on the outside can be designed in many colours. The 6 chamber frame profile ensures superior levels of thermal insulation. Three continuous gaskets protect you home from the wet whilst improving thermal insulation and sound reduction.

I-tec Glazing, the continuous all round bonding of the glass pane, makes this style of window even more stable and boosts burglary protection



Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,69

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 71
  • View width frame/sash 97
  • View width flying mullion (2 sashes) 100
  • View width transom/mullion (2 sashes) 154

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Light grey

KF 320 – uPVC-Aluminium profile

The innovative glass sash of the KF 320 gives the impression of fixed glazing, yet it is still an openable window. The narrow, square edged window frame highlights the minimal architecture of the window design.

This straight lined window profile has an appealingly consistent design. Externally, the opening sash is covered by the window frame. The narrow offset between the frame and the glass pane enhances the flush mount aesthetics The glass sash gives the impression of a fixed glazed unit, yet it is an operable window.

Three sided rendering of the frame achieves modern and almost frameless glass architecture. I-tec glazing ensures excellent stability, thermal insulation and security through surrounding bonding of the glass pane.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,65

Internorm Sonic Icon

Sound Reduction (in dB)

35 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena

  • Frame construction depth 71
  • View width frame/sash 97
  • View width flying mullion (2 sashes) 100
  • View width transom/mullion (2 sashes) 154

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Light grey

KF 410 – uPVC-Aluminium profile

The KF 410 window offers sleek aesthetics with its 93mm construction depth and square edged frame design. This Passivhaus certified window demonstrates thermal insulation, with U-values as low as 0.62 W/m2k.

The KF 410 uPVC aluminium windows are entirely flush from sash to frame. Once the frame is rendered into the brickwork on three sides, only the unique narrow and square edged sash frame remains visible.

The KF 410 window is compliant with the top level accreditations of Secured by Design and Lifetime Homes, key “must have” attributes architects require. Internorm technology is integrated into this energy efficient window offering technological advances that make life easier.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,62

Internorm Sonic Icon

Sound Reduction (in dB)

34 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 90
  • View width frame/sash 113
  • View width flying mullion (2 sashes) 133
  • View width transom/mullion (2 sashes) 187

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets Quantity

  • Quantity 3
  • Colour Light grey

KF 520 – uPVC-Aluminium profile

KF 520 meets the highest demands for burglary protection, thanks to its state of the art locking technology. The sleek frame offers superior levels thermal efficiency and sound reduction for maximum homeowner comfort. This model is also available in the flush mount Studio design, for an ultra modern aesthetic.

The KF 520 uPVC aluminium windows feature a fully integrated locking system, which renders levering of the window impossible. The window sash is not visible externally due to its glass appearance and can optically not be distinguished from fixed glazing.

Optional built in ventilation can be added into the frame with the I-tec Ventilation system. I-tec Glazing ensures excellent stability, thermal insulation, and security due to the all round bonding of the glass pane.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,63

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 46

Internorm Security Icon

Security

up to RC3, RC2

Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 90
  • View width frame/sash 85
  • View width flying mullion (2 sashes) 96
  • View width transom/mullion (2 sashes) 148

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Light grey

KV 350 – uPVC-Aluminium profile

The KV 350 range of uPVC aluminium windows comes with advanced sun protection technology. Designed with market leading integral blinds, these window systems offer sun and privacy protection. This technology is integrated directly between the glass panes, keeping it protected from wind, dirt and bad weather.

This composite window range conveniently integrates blinds in between the glass panes, for maintenance free protect. Choose between the Home Pure square edged profile and the Ambiente rounded edged traditional design.

All Internorm integrated blinds can be powered by a self sufficient photovoltaic panel. This means that no external power source is needed thanks to I-tec Shading. The blinds can be operated with a control panel, remote control, and the I-tec SmartWindow mobile application.  I-tec Glazing ensures excellent stability due to the all round bonding of the glass pane.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0.79

Internorm Sonic Icon

Sound Reduction (in dB)

38 – 44 average

Internorm Security Icon

Security

Secured by Design & PAS 24

Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 74
  • View width frame/sash 112
  • View width flying mullion (2 sashes) 130
  • View width transom/mullion (2 sashes) 181

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Black

KV 440 – uPVC-Aluminium profile

The KV 440 window features integrated blind and advanced Internorm technology. The technology of I-tec Glazing ensures optimum stability as well as superior levels of thermal insulation and sound reduction.

This window features quadruple protection with the sun and privacy protection integrated into the window. The blinds are fitted between panes, protecting them from dirt. They can still be easily accessed to clean, as they feature Internorm Sun and Insect Protection technologies

The energy sufficient I-tec shading doesn’t need an external power source due to the photovoltaic module and batteries. Integrated automatic functions such as day/night recognition and intelligent overheating protection can be integrated.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,64

Internorm Sonic Icon

Sound Reduction (in dB)

39 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 93
  • View width frame/sash 118
  • View width flying mullion (2 sashes) 144
  • View width transom/mullion (2 sashes) 198

    Opening versions

    Gaskets

  • Quantity 3
  • Colour Black

HF 310 – Timber-Aluminium Profile

The HF 310 blends flexibility with a superior double glazing performance. This window takes in the visual benefits of timber with the efficiency and weatherproof properties of modern aluminium. The three continuous gaskets prevent water from meeting the timber surface.

All around gluing of the glass pane ensures excellent stability and offers burglary protection. Three continuous gaskets and external weather resistant aluminium prevent water from entering. The timber elements of the window offer excellent thermal insulation values.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,62

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 46

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 93
  • View width frame/sash 118
  • View width flying mullion (2 sashes) 144
  • View width transom/mullion (2 sashes) 198

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Black

HF 410 – Timber-Aluminium Profile

The HF 410 is one of the most popular and widely requested window systems in our timber-aluminium range. Its versatility, customisation and overall performance levels make it ideal for any size, shape and era of property.

With an 85mm frame depth, you can enjoy the minimalistic aesthetics. All the while, this design enjoys fantastic thermal retention, high quality acoustic insulation and certified security standards.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,64

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 85
  • View width frame/sash 108
  • View width flying mullion (2 sashes) 123
  • View width transom/mullion (2 sashes) 173

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Outward opening doors

  • Quantity 3
  • Colour Black

HV 450 – Timber-Aluminium Profile

The HV 450 comes with Internorm’s innovative integral sun protection hardware as standard. All the while, retaining all the character, delivering eye catching aesthetics and versatility for homeowners.

The HV 450 offers quadruple protection with advanced sun and privacy protection, thermal insulation and sound reduction. The I-tec shading works completely energy self sufficient and offers a host of innovative solutions for homes.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0.62

Internorm Sonic Icon

Sound Reduction (in dB)

41 - 46

Internorm Security Icon

Security

Secured by Design & PAS 24

Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 85
  • View width frame/sash 108
  • View width flying mullion (2 sashes) 123
  • View width transom/mullion (2 sashes) 173

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Black

HF 400 – Timber-Aluminium Profile

The HF 400 is a timber aluminium window system that provides an all round performance without compromising on aesthetics.

This design of composite window has an attractive finish, superior levels of heat protection and multiple security properties. The HF 400 has a door leaf that is flat on both the inside and the outside, and an angular frame profile. The plate construction of the door leaf ensures thermal insulation to passive house standard.

Multipoint locking mechanism with a swing bolt is fitted as standard and maximum stability in the door leaf offers enhanced burglary protection. A wide range of door models with different surfaces, handles and glass cut outs offers the right door for every type of home.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0.70

Internorm Sonic Icon

Sound Reduction (in dB)

35 - 45

Internorm Security Icon

Security

Secured by Design & PAS 24

Internorm Windows Ballymena

Industry Leading uPVC-Aluminium Windows

uPVC aluminium Internorm windows can achieve an exceptional level of thermal insulation. Due to the composite design of these products, they don’t just look stunning, but they can make your building perform highly too. With triple glazed uPVC aluminium, your property will feel cosy and comfortable.

With a unique design, the uPVC aluminium Internorm window uses an aluminium cladding profile on the window exterior to deliver a durable and comprehensive style that makes this incredibly easy t maintain. Retaining their quality appearance for a long time, these windows reach Passive House Standards. Truly perfect.

These windows look incredible, but they require very little upkeep. After our expert team of installers work their magic, there is no need to repaint, stain or treat them as they will constantly maintain their high quality finish and feel for years to come.

Free Online Quote
Internorm Window Costs Ballymena

Internorm uPVC-Aluminium Profiles

KF 310

uPVC / Aluminium

Homepure KF310 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,69

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Homesoft KF310 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,69

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Studio KF310 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,69

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

KF 320

uPVC / Aluminium

Homepure KF310 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,65

Internorm Sonic Icon

Sound Reduction (in dB)

35 - 45

Internorm Security Icon

Security

up to RC1N, RC2

KF 410

uPVC / Aluminium

Homepure KF410 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,62

Internorm Sonic Icon

Sound Reduction (in dB)

34 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Homesoft KF410 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,62

Internorm Sonic Icon

Sound Reduction (in dB)

34 - 45

Internorm Security Icon

Security

up to RC1N, RC2

ambiente KF410 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,62

Internorm Sonic Icon

Sound Reduction (in dB)

34 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Studio KF410 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,62

Internorm Sonic Icon

Sound Reduction (in dB)

34 - 45

Internorm Security Icon

Security

up to RC1N, RC2

KF 520

uPVC / Aluminium

Studio KF520 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,63

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 46

Internorm Security Icon

Security

up to RC1N, RC2

KV 350

uPVC / Aluminium

Homesoft KV350 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,79

Internorm Sonic Icon

Sound Reduction (in dB)

38 - 44

Internorm Security Icon

Security

up to RC1N, RC2

Ambiente KV350 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,79

Internorm Sonic Icon

Sound Reduction (in dB)

38 - 44

Internorm Security Icon

Security

up to RC1N, RC2

Studio KF310 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,69

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

KV 440

uPVC / Aluminium

Homepure KV440 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,69

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Homesoft KV440 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,69

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Studio KV440 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,69

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

KF 410 - uPVC Profile

The KF 410 has a complete flush transition from sash to frame, completing this window as one unit. Once the frame is rendered into the brickwork on three sides, only the unique narrow and square edged sash frame remains visible.

With low U-values, it’s a cost efficient window option with compliant accreditations. Secured By Design and Lifetime Homes accreditations make them an ideal option for any home. Intelligent Internorm technology is integrated into this KF 410 style window system.

I-tec innovations such as I-tec Glazing and I-tec Ventilation ensure optimum stability, thermal insulation and security. These windows are controlled at the touch of a button, enabling simple and stress free operation of your window via smartphone or tablet.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0.62

Internorm Sonic Icon

Sound Reduction (in dB)

34 - 45

Internorm Security Icon

Security

Up to RC1N, RC2

Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimensions (in mm)

  • Frame construction depth 90
  • View width frame/sash 113
  • View width flying mullion (2 sashes) 133
  • View width transom/mullion (2 sashes) 187

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Light grey

KF 520 – uPVC Profile

KF 520 uPVC windows combine innovative design with advanced technology. This window meets the highest standards of burglary protection, with I-tec Secure and innovative locking systems.

Integrated flaps press on all sides into the frame interior when locking and thus ensure maximum burglary protection.

The sleek frame offers excellent thermal efficiency and sound reduction for maximum comfort. Optional built in ventilation can be added into the window frame with the I-tec Ventilation system. I-tec Glazing gives stability, thermal insulation, and security due to the all round bonding of the glass pane.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,63

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 46

Internorm Security Icon

Security

up to RC3, RC2

Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 90
  • View width frame/sash 85
  • View width flying mullion (2 sashes) 96
  • View width transom/mullion (2 sashes) 148

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Light grey

KF 310 – uPVC Profile

The traditional and sophisticated KF 310 has a sleek appearance alongside reliable technology. This range of windows is characterised by thermal insulation and impressive sound reduction values.

With a round bonded glass pane, the KF 310 is available in a large selection of colours, glazing and handles. They can also make the ideal addition to the balcony and patio doors, with integrated Juliet balcony.

I-tec glazing ensures excellent stability. The glass pane is glued all around the frame, ensuring superior levels of security and thermal insulation.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,69

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 90
  • View width frame/sash 85
  • View width flying mullion (2 sashes) 96
  • View width transom/mullion (2 sashes) 148

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Light grey

KF 320 – uPVC Profile

The innovative glass sash of the KF 320 gives the impression of fixed glazing, yet it is still an openable window. The narrow, square edged window frame highlights the minimal architecture of the window design.

This straight lined window profile has an appealingly consistent design. Externally, the opening sash is covered by the window frame. The narrow offset between the frame and the glass pane enhances the flush mount aesthetics The glass sash gives the impression of a fixed glazed unit, yet it is an operable window.

Three sided rendering of the frame achieves modern and almost frameless glass architecture. I-tec glazing ensures excellent stability, thermal insulation and security through surrounding bonding of the glass pane.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,65

Internorm Sonic Icon

Sound Reduction (in dB)

35 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 71
  • View width frame/sash 97
  • View width flying mullion (2 sashes) 100
  • View width transom/mullion (2 sashes) 154

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Light grey

KF 310 – uPVC-Aluminium profile

The FK 310 is a slim window with a construction depth of 74 mm. The rounded edges of sash and frame match design is elegant and cosy.

The strong aluminium cladding on the outside can be designed in many colours. The 6 chamber frame profile ensures superior levels of thermal insulation. Three continuous gaskets protect you home from the wet whilst improving thermal insulation and sound reduction.

I-tec Glazing, the continuous all round bonding of the glass pane, makes this style of window even more stable and boosts burglary protection



Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,69

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 71
  • View width frame/sash 97
  • View width flying mullion (2 sashes) 100
  • View width transom/mullion (2 sashes) 154

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Light grey

KF 320 – uPVC-Aluminium profile

The innovative glass sash of the KF 320 gives the impression of fixed glazing, yet it is still an openable window. The narrow, square edged window frame highlights the minimal architecture of the window design.

This straight lined window profile has an appealingly consistent design. Externally, the opening sash is covered by the window frame. The narrow offset between the frame and the glass pane enhances the flush mount aesthetics The glass sash gives the impression of a fixed glazed unit, yet it is an operable window.

Three sided rendering of the frame achieves modern and almost frameless glass architecture. I-tec glazing ensures excellent stability, thermal insulation and security through surrounding bonding of the glass pane.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,65

Internorm Sonic Icon

Sound Reduction (in dB)

35 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena

  • Frame construction depth 71
  • View width frame/sash 97
  • View width flying mullion (2 sashes) 100
  • View width transom/mullion (2 sashes) 154

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Light grey

KF 410 – uPVC-Aluminium profile

The KF 410 window offers sleek aesthetics with its 93mm construction depth and square edged frame design. This Passivhaus certified window demonstrates thermal insulation, with U-values as low as 0.62 W/m2k.

The KF 410 uPVC aluminium windows are entirely flush from sash to frame. Once the frame is rendered into the brickwork on three sides, only the unique narrow and square edged sash frame remains visible.

The KF 410 window is compliant with the top level accreditations of Secured by Design and Lifetime Homes, key “must have” attributes architects require. Internorm technology is integrated into this energy efficient window offering technological advances that make life easier.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,62

Internorm Sonic Icon

Sound Reduction (in dB)

34 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 90
  • View width frame/sash 113
  • View width flying mullion (2 sashes) 133
  • View width transom/mullion (2 sashes) 187

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets Quantity

  • Quantity 3
  • Colour Light grey

KF 520 – uPVC-Aluminium profile

KF 520 meets the highest demands for burglary protection, thanks to its state of the art locking technology. The sleek frame offers superior levels thermal efficiency and sound reduction for maximum homeowner comfort. This model is also available in the flush mount Studio design, for an ultra modern aesthetic.

The KF 520 uPVC aluminium windows feature a fully integrated locking system, which renders levering of the window impossible. The window sash is not visible externally due to its glass appearance and can optically not be distinguished from fixed glazing.

Optional built in ventilation can be added into the frame with the I-tec Ventilation system. I-tec Glazing ensures excellent stability, thermal insulation, and security due to the all round bonding of the glass pane.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,63

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 46

Internorm Security Icon

Security

up to RC3, RC2

Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 90
  • View width frame/sash 85
  • View width flying mullion (2 sashes) 96
  • View width transom/mullion (2 sashes) 148

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Light grey

KV 350 – uPVC-Aluminium profile

The KV 350 range of uPVC aluminium windows comes with advanced sun protection technology. Designed with market leading integral blinds, these window systems offer sun and privacy protection. This technology is integrated directly between the glass panes, keeping it protected from wind, dirt and bad weather.

This composite window range conveniently integrates blinds in between the glass panes, for maintenance free protect. Choose between the Home Pure square edged profile and the Ambiente rounded edged traditional design.

All Internorm integrated blinds can be powered by a self sufficient photovoltaic panel. This means that no external power source is needed thanks to I-tec Shading. The blinds can be operated with a control panel, remote control, and the I-tec SmartWindow mobile application.  I-tec Glazing ensures excellent stability due to the all round bonding of the glass pane.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0.79

Internorm Sonic Icon

Sound Reduction (in dB)

38 – 44 average

Internorm Security Icon

Security

Secured by Design & PAS 24

Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 74
  • View width frame/sash 112
  • View width flying mullion (2 sashes) 130
  • View width transom/mullion (2 sashes) 181

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Black

KV 440 – uPVC-Aluminium profile

The KV 440 window features integrated blind and advanced Internorm technology. The technology of I-tec Glazing ensures optimum stability as well as superior levels of thermal insulation and sound reduction.

This window features quadruple protection with the sun and privacy protection integrated into the window. The blinds are fitted between panes, protecting them from dirt. They can still be easily accessed to clean, as they feature Internorm Sun and Insect Protection technologies

The energy sufficient I-tec shading doesn’t need an external power source due to the photovoltaic module and batteries. Integrated automatic functions such as day/night recognition and intelligent overheating protection can be integrated.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,64

Internorm Sonic Icon

Sound Reduction (in dB)

39 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 93
  • View width frame/sash 118
  • View width flying mullion (2 sashes) 144
  • View width transom/mullion (2 sashes) 198

    Opening versions

    Gaskets

  • Quantity 3
  • Colour Black

HF 310 – Timber-Aluminium Profile

The HF 310 blends flexibility with a superior double glazing performance. This window takes in the visual benefits of timber with the efficiency and weatherproof properties of modern aluminium. The three continuous gaskets prevent water from meeting the timber surface.

All around gluing of the glass pane ensures excellent stability and offers burglary protection. Three continuous gaskets and external weather resistant aluminium prevent water from entering. The timber elements of the window offer excellent thermal insulation values.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,62

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 46

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 93
  • View width frame/sash 118
  • View width flying mullion (2 sashes) 144
  • View width transom/mullion (2 sashes) 198

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Black

HF 410 – Timber-Aluminium Profile

The HF 410 is one of the most popular and widely requested window systems in our timber-aluminium range. Its versatility, customisation and overall performance levels make it ideal for any size, shape and era of property.

With an 85mm frame depth, you can enjoy the minimalistic aesthetics. All the while, this design enjoys fantastic thermal retention, high quality acoustic insulation and certified security standards.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,64

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 85
  • View width frame/sash 108
  • View width flying mullion (2 sashes) 123
  • View width transom/mullion (2 sashes) 173

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Outward opening doors

  • Quantity 3
  • Colour Black

HV 450 – Timber-Aluminium Profile

The HV 450 comes with Internorm’s innovative integral sun protection hardware as standard. All the while, retaining all the character, delivering eye catching aesthetics and versatility for homeowners.

The HV 450 offers quadruple protection with advanced sun and privacy protection, thermal insulation and sound reduction. The I-tec shading works completely energy self sufficient and offers a host of innovative solutions for homes.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0.62

Internorm Sonic Icon

Sound Reduction (in dB)

41 - 46

Internorm Security Icon

Security

Secured by Design & PAS 24

Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 85
  • View width frame/sash 108
  • View width flying mullion (2 sashes) 123
  • View width transom/mullion (2 sashes) 173

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Black

HF 400 – Timber-Aluminium Profile

The HF 400 is a timber aluminium window system that provides an all round performance without compromising on aesthetics.

This design of composite window has an attractive finish, superior levels of heat protection and multiple security properties. The HF 400 has a door leaf that is flat on both the inside and the outside, and an angular frame profile. The plate construction of the door leaf ensures thermal insulation to passive house standard.

Multipoint locking mechanism with a swing bolt is fitted as standard and maximum stability in the door leaf offers enhanced burglary protection. A wide range of door models with different surfaces, handles and glass cut outs offers the right door for every type of home.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0.70

Internorm Sonic Icon

Sound Reduction (in dB)

35 - 45

Internorm Security Icon

Security

Secured by Design & PAS 24

Internorm Windows Ballymena
Internorm Windows Ballymena Modern

Internorm Timber-Aluminium Windows

Timber aluminium windows are a combination of timber and aluminium materials used to create a window design that is strong, durable, and stable for any building they are installed in. With its abilities, you can receive a long lasting investment for your Ballymena property. This composite window style results in the sense of comfort and warmth throughout the year.

The external aluminium cladding, combined with triple or double glazing, protects the timber core from weathering out. A layer of foam is placed between different materials to deliver optimal thermal efficiency every day. When you choose timber aluminium Internorm windows, your property will receive a complete home improvement solution that you will not be able to find anywhere else on the market.

Our timber aluminium Internorm windows reach Passive House Standards and enable your property to achieve the highest performance values that other timber window alternatives cannot. Discover more by getting in touch with a friendly team member today!

Contact Us Today

Internorm Timber-Aluminium Window Profiles

HF 310

Timber / Aluminium

Homepure HF310 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,62

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 46

Internorm Security Icon

Security

up to RC1N, RC2

Homesoft HF310 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,69

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Ambiente HF310 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,69

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Studio HF310 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,69

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

HF 400

Timber / Aluminium

Homepure HF400 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,70

Internorm Sonic Icon

Sound Reduction (in dB)

35 - 45

Internorm Security Icon

Security

up to RC1N, RC2

HF 410

Timber / Aluminium

Homepure HF410 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,64

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Homesoft HF410 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,64

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Ambiente HF410 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,64

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Studio HF410 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,64

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

HV 450

Timber / Aluminium

Homepure HV450 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,62

Internorm Sonic Icon

Sound Reduction (in dB)

41 - 46

Internorm Security Icon

Security

up to RC1N, RC2

Homesoft HV450 Internorm Profile
Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,62

Internorm Sonic Icon

Sound Reduction (in dB)

41 - 46

Internorm Security Icon

Security

up to RC1N, RC2

KF 410 - uPVC Profile

The KF 410 has a complete flush transition from sash to frame, completing this window as one unit. Once the frame is rendered into the brickwork on three sides, only the unique narrow and square edged sash frame remains visible.

With low U-values, it’s a cost efficient window option with compliant accreditations. Secured By Design and Lifetime Homes accreditations make them an ideal option for any home. Intelligent Internorm technology is integrated into this KF 410 style window system.

I-tec innovations such as I-tec Glazing and I-tec Ventilation ensure optimum stability, thermal insulation and security. These windows are controlled at the touch of a button, enabling simple and stress free operation of your window via smartphone or tablet.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0.62

Internorm Sonic Icon

Sound Reduction (in dB)

34 - 45

Internorm Security Icon

Security

Up to RC1N, RC2

Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimensions (in mm)

  • Frame construction depth 90
  • View width frame/sash 113
  • View width flying mullion (2 sashes) 133
  • View width transom/mullion (2 sashes) 187

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Light grey

KF 520 – uPVC Profile

KF 520 uPVC windows combine innovative design with advanced technology. This window meets the highest standards of burglary protection, with I-tec Secure and innovative locking systems.

Integrated flaps press on all sides into the frame interior when locking and thus ensure maximum burglary protection.

The sleek frame offers excellent thermal efficiency and sound reduction for maximum comfort. Optional built in ventilation can be added into the window frame with the I-tec Ventilation system. I-tec Glazing gives stability, thermal insulation, and security due to the all round bonding of the glass pane.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,63

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 46

Internorm Security Icon

Security

up to RC3, RC2

Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 90
  • View width frame/sash 85
  • View width flying mullion (2 sashes) 96
  • View width transom/mullion (2 sashes) 148

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Light grey

KF 310 – uPVC Profile

The traditional and sophisticated KF 310 has a sleek appearance alongside reliable technology. This range of windows is characterised by thermal insulation and impressive sound reduction values.

With a round bonded glass pane, the KF 310 is available in a large selection of colours, glazing and handles. They can also make the ideal addition to the balcony and patio doors, with integrated Juliet balcony.

I-tec glazing ensures excellent stability. The glass pane is glued all around the frame, ensuring superior levels of security and thermal insulation.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,69

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 90
  • View width frame/sash 85
  • View width flying mullion (2 sashes) 96
  • View width transom/mullion (2 sashes) 148

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Light grey

KF 320 – uPVC Profile

The innovative glass sash of the KF 320 gives the impression of fixed glazing, yet it is still an openable window. The narrow, square edged window frame highlights the minimal architecture of the window design.

This straight lined window profile has an appealingly consistent design. Externally, the opening sash is covered by the window frame. The narrow offset between the frame and the glass pane enhances the flush mount aesthetics The glass sash gives the impression of a fixed glazed unit, yet it is an operable window.

Three sided rendering of the frame achieves modern and almost frameless glass architecture. I-tec glazing ensures excellent stability, thermal insulation and security through surrounding bonding of the glass pane.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,65

Internorm Sonic Icon

Sound Reduction (in dB)

35 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 71
  • View width frame/sash 97
  • View width flying mullion (2 sashes) 100
  • View width transom/mullion (2 sashes) 154

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Light grey

KF 310 – uPVC-Aluminium profile

The FK 310 is a slim window with a construction depth of 74 mm. The rounded edges of sash and frame match design is elegant and cosy.

The strong aluminium cladding on the outside can be designed in many colours. The 6 chamber frame profile ensures superior levels of thermal insulation. Three continuous gaskets protect you home from the wet whilst improving thermal insulation and sound reduction.

I-tec Glazing, the continuous all round bonding of the glass pane, makes this style of window even more stable and boosts burglary protection



Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,69

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 71
  • View width frame/sash 97
  • View width flying mullion (2 sashes) 100
  • View width transom/mullion (2 sashes) 154

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Light grey

KF 320 – uPVC-Aluminium profile

The innovative glass sash of the KF 320 gives the impression of fixed glazing, yet it is still an openable window. The narrow, square edged window frame highlights the minimal architecture of the window design.

This straight lined window profile has an appealingly consistent design. Externally, the opening sash is covered by the window frame. The narrow offset between the frame and the glass pane enhances the flush mount aesthetics The glass sash gives the impression of a fixed glazed unit, yet it is an operable window.

Three sided rendering of the frame achieves modern and almost frameless glass architecture. I-tec glazing ensures excellent stability, thermal insulation and security through surrounding bonding of the glass pane.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,65

Internorm Sonic Icon

Sound Reduction (in dB)

35 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena

  • Frame construction depth 71
  • View width frame/sash 97
  • View width flying mullion (2 sashes) 100
  • View width transom/mullion (2 sashes) 154

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Light grey

KF 410 – uPVC-Aluminium profile

The KF 410 window offers sleek aesthetics with its 93mm construction depth and square edged frame design. This Passivhaus certified window demonstrates thermal insulation, with U-values as low as 0.62 W/m2k.

The KF 410 uPVC aluminium windows are entirely flush from sash to frame. Once the frame is rendered into the brickwork on three sides, only the unique narrow and square edged sash frame remains visible.

The KF 410 window is compliant with the top level accreditations of Secured by Design and Lifetime Homes, key “must have” attributes architects require. Internorm technology is integrated into this energy efficient window offering technological advances that make life easier.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,62

Internorm Sonic Icon

Sound Reduction (in dB)

34 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 90
  • View width frame/sash 113
  • View width flying mullion (2 sashes) 133
  • View width transom/mullion (2 sashes) 187

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets Quantity

  • Quantity 3
  • Colour Light grey

KF 520 – uPVC-Aluminium profile

KF 520 meets the highest demands for burglary protection, thanks to its state of the art locking technology. The sleek frame offers superior levels thermal efficiency and sound reduction for maximum homeowner comfort. This model is also available in the flush mount Studio design, for an ultra modern aesthetic.

The KF 520 uPVC aluminium windows feature a fully integrated locking system, which renders levering of the window impossible. The window sash is not visible externally due to its glass appearance and can optically not be distinguished from fixed glazing.

Optional built in ventilation can be added into the frame with the I-tec Ventilation system. I-tec Glazing ensures excellent stability, thermal insulation, and security due to the all round bonding of the glass pane.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,63

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 46

Internorm Security Icon

Security

up to RC3, RC2

Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 90
  • View width frame/sash 85
  • View width flying mullion (2 sashes) 96
  • View width transom/mullion (2 sashes) 148

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Light grey

KV 350 – uPVC-Aluminium profile

The KV 350 range of uPVC aluminium windows comes with advanced sun protection technology. Designed with market leading integral blinds, these window systems offer sun and privacy protection. This technology is integrated directly between the glass panes, keeping it protected from wind, dirt and bad weather.

This composite window range conveniently integrates blinds in between the glass panes, for maintenance free protect. Choose between the Home Pure square edged profile and the Ambiente rounded edged traditional design.

All Internorm integrated blinds can be powered by a self sufficient photovoltaic panel. This means that no external power source is needed thanks to I-tec Shading. The blinds can be operated with a control panel, remote control, and the I-tec SmartWindow mobile application.  I-tec Glazing ensures excellent stability due to the all round bonding of the glass pane.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0.79

Internorm Sonic Icon

Sound Reduction (in dB)

38 – 44 average

Internorm Security Icon

Security

Secured by Design & PAS 24

Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 74
  • View width frame/sash 112
  • View width flying mullion (2 sashes) 130
  • View width transom/mullion (2 sashes) 181

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Black

KV 440 – uPVC-Aluminium profile

The KV 440 window features integrated blind and advanced Internorm technology. The technology of I-tec Glazing ensures optimum stability as well as superior levels of thermal insulation and sound reduction.

This window features quadruple protection with the sun and privacy protection integrated into the window. The blinds are fitted between panes, protecting them from dirt. They can still be easily accessed to clean, as they feature Internorm Sun and Insect Protection technologies

The energy sufficient I-tec shading doesn’t need an external power source due to the photovoltaic module and batteries. Integrated automatic functions such as day/night recognition and intelligent overheating protection can be integrated.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,64

Internorm Sonic Icon

Sound Reduction (in dB)

39 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 93
  • View width frame/sash 118
  • View width flying mullion (2 sashes) 144
  • View width transom/mullion (2 sashes) 198

    Opening versions

    Gaskets

  • Quantity 3
  • Colour Black

HF 310 – Timber-Aluminium Profile

The HF 310 blends flexibility with a superior double glazing performance. This window takes in the visual benefits of timber with the efficiency and weatherproof properties of modern aluminium. The three continuous gaskets prevent water from meeting the timber surface.

All around gluing of the glass pane ensures excellent stability and offers burglary protection. Three continuous gaskets and external weather resistant aluminium prevent water from entering. The timber elements of the window offer excellent thermal insulation values.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,62

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 46

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 93
  • View width frame/sash 118
  • View width flying mullion (2 sashes) 144
  • View width transom/mullion (2 sashes) 198

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Black

HF 410 – Timber-Aluminium Profile

The HF 410 is one of the most popular and widely requested window systems in our timber-aluminium range. Its versatility, customisation and overall performance levels make it ideal for any size, shape and era of property.

With an 85mm frame depth, you can enjoy the minimalistic aesthetics. All the while, this design enjoys fantastic thermal retention, high quality acoustic insulation and certified security standards.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0,64

Internorm Sonic Icon

Sound Reduction (in dB)

33 - 45

Internorm Security Icon

Security

up to RC1N, RC2

Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 85
  • View width frame/sash 108
  • View width flying mullion (2 sashes) 123
  • View width transom/mullion (2 sashes) 173

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Outward opening doors

  • Quantity 3
  • Colour Black

HV 450 – Timber-Aluminium Profile

The HV 450 comes with Internorm’s innovative integral sun protection hardware as standard. All the while, retaining all the character, delivering eye catching aesthetics and versatility for homeowners.

The HV 450 offers quadruple protection with advanced sun and privacy protection, thermal insulation and sound reduction. The I-tec shading works completely energy self sufficient and offers a host of innovative solutions for homes.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0.62

Internorm Sonic Icon

Sound Reduction (in dB)

41 - 46

Internorm Security Icon

Security

Secured by Design & PAS 24

Internorm Windows Ballymena
Internorm Windows Ballymena

    Dimension (in mm)

  • Frame construction depth 85
  • View width frame/sash 108
  • View width flying mullion (2 sashes) 123
  • View width transom/mullion (2 sashes) 173

    Opening versions

  • Fixed
  • Turn and turn/tilt
  • Tilt
  • Sliding window
  • Lockable doors
  • Sliding doors
  • Doors with threshold
  • Outward opening doors

    Gaskets

  • Quantity 3
  • Colour Black

HF 400 – Timber-Aluminium Profile

The HF 400 is a timber aluminium window system that provides an all round performance without compromising on aesthetics.

This design of composite window has an attractive finish, superior levels of heat protection and multiple security properties. The HF 400 has a door leaf that is flat on both the inside and the outside, and an angular frame profile. The plate construction of the door leaf ensures thermal insulation to passive house standard.

Multipoint locking mechanism with a swing bolt is fitted as standard and maximum stability in the door leaf offers enhanced burglary protection. A wide range of door models with different surfaces, handles and glass cut outs offers the right door for every type of home.

Internorm Temperature Icon

Thermal Insulation (in W/m²K)

Uw up to 0.70

Internorm Sonic Icon

Sound Reduction (in dB)

35 - 45

Internorm Security Icon

Security

Secured by Design & PAS 24

Internorm Windows Ballymena

Customer Focused

Here at Feneco Systems, we strive in placing our valued customers at the forefront of everything we do. Not just this, but our team are top experts in the industry and can provide you with the very best advice for your home improvement projects.

Get in Touch
Internorm Windows Passive House Ballymena

Internorm Window Prices Online, Ballymena

To find out more about our Internorm windows, get in touch with us today. You can receive a FREE online quotation by clicking the button on the right hand side of this page. Choose the Internorm windows of your choice here at Feneco.

Online Quote
